Phoenix LiFePO4 Battery
Phoenix Series – 48V LiFePO4 Battery for Solar Energy Storage
The SVC Phoenix Series is a premium line of 48V LiFePO4 battery modules, designed for modern solar energy storage applications. Whether you’re powering a smart home, upgrading a commercial system, or preparing for off-grid living, this solar battery with BMS delivers long-lasting reliability, advanced control, and seamless inverter compatibility.
Reliable Power with Modular Flexibility
Available in both 5kWh and 10kWh capacities, the Phoenix Series offers scalable energy storage. Up to 16 units can be connected in parallel, allowing you to build a flexible solar energy storage solution that grows with your needs. This 48V LiFePO4 battery is perfect for residential backup, hybrid inverters, and commercial setups.
Smart BMS for Intelligent Protection
Each unit comes with a built-in smart BMS (Battery Management System), providing full protection against overcharge, over-discharge, overcurrent, short-circuit, and temperature extremes. The solar battery with BMS ensures optimal performance and extends lifespan beyond 6000 cycles at 80% DoD.
Seamless Integration with Solar Inverters
The Phoenix Series is engineered for smooth integration with most leading solar inverter brands. It features advanced communication interfaces (RS485, CAN, Bluetooth, WiFi, SNMP), making it a highly compatible 48V LiFePO4 battery system. Whether you're on-grid or off-grid, this battery adapts to your solar energy storage needs with ease.
Compact, Versatile, and Easy to Install
With both wall-mounted and floor-mounted options, the Phoenix Series saves space and simplifies installation. The front LCD display provides real-time monitoring, while silent operation (<40dB) ensures it blends into any environment. This solar battery with BMS is ideal for smart homes, microgrids, and small businesses seeking clean, efficient power.
Key Benefits:
- 48V LiFePO4 battery with 5kWh/10kWh capacity
- Over 6000 life cycles with high energy density
- Compatible with hybrid/off-grid inverters
- Advanced BMS and multiple communication options
- Modular design for scalable solar energy storage
Whether you're preparing for load shedding, expanding your solar setup, or upgrading backup power systems, the Phoenix Series 48V LiFePO4 battery is your go-to solar battery with BMS — smart, safe, and scalable for every energy challenge.
Specifications
MODEL | Phoenix 24-200 | Phoenix 48-100 | Phoenix 48-200 |
SPECIFICATION | |||
Battery Type | LiFePO4 | LiFePO4 | LiFePO4 |
Battery Model | 25.6V200AH | 51.2V100AH | 51.2V100AH |
Nominal Capacity (25℃，0.2C)WH | 5120Wh | 5120Wh | 10240Wh |
Adjustable working voltage (Vdc) | 22.4～29.2V | 42～54.8V | 42～54.8V |
Folat Charge Voltage (Vdc) | 28V | 56V | 56V |
Max. Continuous discharge current (A) | 100 | 100 | 200 |
Max.pulse discharge current(A) | 150A (1 sec) configurable | 300A (1 sec) configurable | |
Max.Continuous charge current(A) | 100 | 100 | 200 |
Cycle life(25℃ 0.2C 80% DOD) | ＞6000 Cycles | ＞6000 Cycles | ＞6000 Cycles |
Cell Equalizer Current(A) | 0.1～5A Max.(optional) | 0.1～5A Max.(optional) | 0.1～5A Max.(optional) |
Terminal | Up to 16pcs | ||
Storage duration | 6 months at 25℃ | ||
Safety standard | IEC62619,UN38.3,MSDS,CE | ||
Communication function | RS485/CAN(Standard), SNMP/Wifi/Bluetooth(Optional) | ||
PROTECTION | |||
Protection | Overcharge protection/ Overdischarge protection/ Overcurrent protection | ||
AMBIENT | |||
Noise(dB) | ＜40dB(1 meter) | ||
Working temperature | -20℃～+60℃ | ||
Humidity | 0～95%(no condensation) | ||
Altitude(m) | <3000 | ||
DIMENSION | |||
W*H*D(Product size)mm | 442*590*152 | 550*800*175.5 | |
W*H*D(Package size)mm | 523*706*224 | 654*980*373 | |
Net Weight(Kg) | 48 | 84 | |
Gross Weight(Kg) | 63 | 104 | |
*Product specifications are subject to change without notice.
