12V LiFePO4 replacement for lead-acid batteries, ideal for solar and RV systems

RV and marine 12V LiFePO4 battery for solar energy systems

Model No: 12V-100Ah/12V-230Ah

LFP 12V-100Ah/12V-230Ah Lithium Battery

Quantity :

Contact Now

All Products

Subscribe to our Newsletter

Power Your Energy Independence with SVC’s 12V LiFePO4 Battery – The Ultimate Solar Battery Storage Solution!

Introducing the SVC LFP Series 12V LiFePO4 Battery – engineered for unmatched durability, intelligence, and performance in renewable energy systems. As a premium solar battery storage 12V solution, it delivers 3,000+ deep cycles at 100% DoD, IP65 ruggedness, and Bluetooth connectivity for smarter energy management. Perfect for solar installations, off-grid setups, and mobile applications, this 12V LiFePO4 battery redefines reliability.

Unbeatable Longevity & Performance
Experience industry-leading value with our 3000 cycle lithium battery technology. Unlike lead-acid alternatives, these lithium iron phosphate batteries:

Last 8–10× longer with >3,000 cycles at 100% depth of discharge (DoD).
Operate in extreme temperatures (-20°C to 60°C).
Weigh 40–50% less (e.g., 100Ah model: just 11.8kg).
Deliver zero maintenance and built-in cell balancing.

Smart Energy Control
Upgrade to a Bluetooth solar battery (available for 50Ah+ models) for real-time monitoring:

Track voltage, cycles, and health via mobile app.
Optimize charging from solar/grid sources.
Receive alerts for overcharge/over-discharge.
Pair up to 4 batteries in series for 24V/48V systems – ideal for scaling your solar battery storage 12V setup.

Applications :
This 3000 cycle lithium battery excels where reliability matters:

Solar/Wind Storage: Robust solar battery storage 12V for off-grid homes.
E-Mobility: Power golf carts, e-rickshaws & EVs.
Critical Backup: Uninterrupted UPS/telecom power.
Marine/RV: Vibration-resistant IP65 design.

Why Choose This 12V LiFePO4 Battery?

✅ Future-Proof: 10+ year lifespan with 3000+ cycles.
✅ All-Weather Ready: -20°C to 60°C operation.
✅ Plug-and-Play: Works with standard lead-acid chargers.
✅ Eco-Smart: 100% recyclable, zero emissions.

The SVC LFP 12V LiFePO4 battery is the intelligent cornerstone for renewable energy systems. As a Bluetooth solar battery, it offers unmatched control, while its 3000 cycle lithium battery endurance ensures decades of service. For scalable, maintenance-free solar battery storage 12V – whether for cabins, RVs, or solar farms – this is the investment that pays for itself.

Lithium Battery

Specifications

Model	LFP12-07	LFP12-09	LFP12-24	LFP12-36	LFP12-50 L	LFP12-100	LFP12-150	LFP12-200
Norminal voltage	12.8V	12.8V	12.8V	12.8V	12.8V	12.8V	12.8V	12.8V
Nominal Capacity @0.2C	7.2Ah	9Ah	21.6Ah	36Ah	50Ah	100Ah	150Ah	200Ah
Energy(Wh)	92.1Wh	115.2Wh	276.4Wh	460.8Wh	640Wh	1280Wh	1920Wh	2560Wh
Cycle Life	>3000 Cycles @ 0.5C Charge/Discharge at 100%DOD,End of Life 70% Capacity
Months Self Discharge	≤3.5% per month at 25℃
Standard Charge
Charge Voltage	14.4±0.2V
Charge Mode (CC/CV)	At 0℃~50℃ temperature, charged to 14.4V at a constant current of 0.5C, and then,changed continuously with constant voltage of 14.4V until the current was not more than 0.02C
Max.continuous Charge Current	7.2A	10A	22A	36A	50A	100A	100A	100A
Standard Discharge
Max. Continuous Discharging Current	10A	13A	32A	40A	50A	100A	100A	100A
Max.Pulse Current	20A @10S	20A @10S	60A @10S	80A @10S	100A@10S	200A @ 10S	200A @ 10S	200A @ 10S
Discharge Cut-off Voltage	9.8V
Environmental
Charge Temperature	0℃ to 50℃(32℉ to 113℉)@60±25% Relative Humidity
Discharge Temperature	-20℃ to 60℃(-4℉ to 140℉)@60±25% Relative Humidity
Storage Temperature	0℃ to 45℃(32℉ to 113℉) @60±25% Relative Humidity
Water Dust Resistance	IP65
Mechanical
Plastic Case	ABS
Dimension(LWH) (mm)	9070107	15165100	18177167	198166170	229138213	328172215	328172215	522240218
Approx. Weight(Kg)	0.9	0.97	2.1	4.5	6.5	11.8	16.5	18.8
Terminal	T2	T2	M5	M8	M6	M8	M8	M8

*Product specifications are subject to change without notice.
